REMOVABLE FIRE BARRIER PARTITION 1H, 98 MM THICK, UNDER JOINT COVER, CONFORMS TO DTU 35.1, SUITABLE FOR THE LAYOUT OF SPACES REQUIRING FIRE RESISTANCE.
Presentation:
Removable partition system to meet the specificities of certain areas requiring high fire resistance, our removable fire barrier or flame shield 1h is a solid partition Ei60 steel frame.
Composed of four panels per module, HPF-60 offers excellent sound insulation for added comfort.
The aesthetics are also guaranteed: the joint covers and rails are in lacquered aluminum and the second facings are covered with a decoration of your choice to harmonize all the premises.
![](https://www.qovans.com/wp-content/uploads/2023/02/ERDF-Lyon-30.jpg)
CONFIGURATION of our full partition EI60
Full height
Height up to 3600 mm
List of PVs available on request at
FULL FILLS:
A first skin composed of a fire-resistant raw plasterboard associated with a 40 mm thick
rock wool A second skin of your choice:
PVC coated plasterboard or pre-lacquered
flat sheet In PVC-coated
cellulose fiber sheet In melamine panel 12 mm In wood chipboard 12 mm PVC
coated In compact laminate 12.5 mm
DOORS:
In lacquered steel, the frame of the HPF-60 partition accommodates both wooden doors and metal doors.
USES of our removable partition walls:
Computer
rooms Circulations
