WOOD PANELS FOR THE INTERIOR LAYOUT OF MODULAR BUILDINGS.
Our know-how in modular and removable freestanding partitions allows us to position ourselves among the major players in the prefabricated office fitting sector thanks to a national presence and French production.
Presentation:
These wood panels interior layout adapt perfectly to the configurations and technical and aesthetic constraints related to the development of modular buildings.
Our offers of partitions for industrialized modular constructions are worded as follows: FONTEX MUR - FONTEX BLOC and FONTEX®®® FLAM
FONTEX® MUR :
Wood panel 50mm thick, consisting of 2 wood chipboard facings glued on cleats
Air blade
Weight 23 kg / m²
Acoustics: 29 dB
Reaction to fire: M3 or M1
FONTEX® BLOC:
Wood panel thickness 70mm, consisting of 2 wood chipboard facings glued on cleats
Glass wool thickness 45 mm, density 15 kg / m3
Weight 26 kg / m²
Acoustics: 38 dB
Reaction to fire: M3 or M1
FONTEX® FLAM :
Wood panel 50mm thick, with 2 reinforced cellulose plasterboard facings glued on 18mm cleats.
Rock wool core thickness, density 40 kg / m3
Weight 32 kg / m²
Acoustics: 40 dB or 59 dB in double
mounting Fire resistance: Ei30 up to 2700 mm
Reaction to fire: M0 raw panel or M1 PVC coated panel
MOST PRODUCED:
Self-supporting
structure Coated finish to save time
Variety of finishes
Reaction to fire classification in accordance with standards in ERP
MOUNTING SYSTEM:
For each panel intended for manufacturers or communities, FONTEX® offers you its joinery assembly solution. You are free to select your accessories according to the needs of your site.
USES:
Circulations
Offices
Living spaces
